• Specification:

    • Current Rating : 1.5 Amp
    • Insulator Resistance : 500 Megohms min.
    • Voltage Rating : 125V AC/DC
    • Contact Resistance : 20 Milliohms Max.
    • Dielectric Withstanding : AC 1000 V
    • Operating Temperature : -40%%dC ~ +80%%dC
    • Contact Material : 0.35*0.45mm Dia. Phosphor Bronze
    • Insulator Material : Polyester, UL 94V-0, Standard :PBT
    • Contact Plated : Gold in Contact Area,Tin in, Tail Area Both Over Nickel

    002
