• 0.1" (2.54mm) Pin Header
    • Single Row 02 to 40 Contacts U Style Type


    Specification:

    • Current Rating: 3.0 Amp
    • Insulator Resistance: 1000 Megohms min.
    • Contact Resistance: 20Milliohms Max.
    • Dielectric Withstanding: AC 500V
    • Operating Temperature: -40℃ ~ +105℃
    • Contact Material: Brass
    • Insulator Material: Polyester, UL 94V-0
    • Standard : P.B.T&Nylon-6T
    • Contact Plated: Full Gold, Full Tin,Selective Plated

    P104-11xXXUXX-XX

Order / Inquiry Information

Please select Items below and click See Catelog for Inquiry.
Series No. P104
Series of No. 1: P2.54
Row Type 1:1 Row
No. of Contact
Terminal Type U: U Style Type
Contact Plated
Terminal Type
