F238 Dual Row 04 to 60 Contacts Straight Type

• 0.079”(2.0mm) Female Header
• Dual Row 04 to 60 Contacts
• Straight Type Profile : 6.35mm


Specification:

• Current Rating : 1Amp
• Insulator Resistance: 1000 Megohms min.
• Contact Resistance: AC 500V
• Operating Temperature: -40°C ~ +105°C
• Max Processing Temp : 230°C For 30~60 Seconds (260°C For 10 Seconds)
• Contact Material: Phosphor Bronze
• Insulator Material : Polyester, UL 94V-0
• Standard: Nylon-6T & LCP
• Contact Plated: Full Gold, Full Tin, Selective Plated
• Standard : Gold Flash all Over Nickel
