F212A Dual Row 04 to 80 Contacts Bottom Entry STRAIGHT Type

• 0.079”(2.0mm) Female Header
• Dual Row 04 to 80 Contacts
• Bottom Entry STRAIGHT Type Profile: 4.3mm


Specification:

• Current Rating : 1Amp
• Insulator Resistance : 1000 Megohms min.
• Contact Resistance : 20 Milliohms Max.
• Dielectric Withstanding : AC 500V
• Operating Temperature : -40°C ~ +105°C
• Max Processing Temp : 230°C For 30~60 Seconds (260°C For 10 Seconds)
• Contact Material : Phosphor Bronze
• Insulator Material : Polyester, UL 94V-0
• Standard : Nylon-6T
• Contact Plated : Full Gold, Full Tin, Selective Plated
