B304A 0.05"X0.1"(1.27X2.54mm) Shrouded Header

• 0.05"X0.1"(1.27X2.54mm) Shrouded Header
• Dual Row 20 to 100 Contacts
• Straight And Right Angle Type


Specification:

• Current Rating: 3.0 Amp
• Insulator Resistance: 1000 M ohm min.
• Contact Resistance: 20m ohm Max.
• Dielectric Withstanding: 500 V AC/Min.
• Operating Temperature: -40℃ ~ +105℃
• Contact Material: Phosphor Bronze or Brass
• Insulator Material: Polyester, UL 94V-0
• Standard : P.B.T
• Contact Plated: Full Gold, Full Tin,Selective Plated
• Standard: Gold Flash all Over Nickel
