F226A Single Row 02 to 50 Contacts Straight Type

• 0.05”(1.27mm) Female Header
• Single Row 02 to 50 Contacts
• Straight Type Profile : 3.4mm


Specification:

• Current Rating : 1Amp
• Insulator Resistance : 1000 Megohms min.
• Contact Resistance : 20 Milliohms Max.
• Dielectric Temperature : AC 500V
• Operating Temperature :-40°C ~ +105°C
• Max Processing Temp : 230°C For 30~60 Seconds (260°C For 10 Seconds)
• Contact Material : Phosphor Bronze
• Insulator Material : Polyester, UL 94V-0
• Standard : Nylon-6T
• Contact Plated : Full Gold, Full Tin
• Standard : Gold Flash all Over Nickel
