F235A Single Row 02 to 40 Contacts Straight Type

• 0.1”(2.54mm) Female Header
• Single Row 02 to 40 Contacts
• Straight Type Profile : 8.5mm


Specification:

• Current Rating : 3Amp
• Insulator Resistance : 1000 Megohms min.
• Contact Resistance : 20 Milliohms Max.
• Dielectric Withstanding : AC 500V
• Operating Temperature : -40°C ~ +105°C
• Contact Material : Phosphor Bronze
• Insulator Material : Polyester, UL 94V-0
• Standard : P.B.T & NY-6T & NY-66
• Contact Plated : Full Gold, Full Tin, Selective Plated
• Standard : Gold Flash all Over Nickel
